Automatic Backwash Disk Water Pre-filter
This automatic backwash disk pre-filter is engineered for efficient removal of particulate matter from water sources. It features a stack of grooved disks to trap debris and an automatic backwash cycle that flushes accumulated contaminants.
Technical Specifications
Product Overview
Advanced Automatic Disk Filtration
This automatic backwash disk pre-filter provides a robust solution for removing sediment, rust, and particulate matter from water lines. Utilizing advanced disk filtration technology, the system ensures consistent water quality with a precision of 50μm. It features fully automated backwash cycles triggered by time or filtration monitoring, significantly reducing the need for manual maintenance and ensuring continuous, reliable operation.
Technical Specifications
Model Comparison
| Model | Rated Flow Rate | Inlet/Outlet | Drain Line |
|---|---|---|---|
| RL-Q01 | 1.5m3/h | G3/4 | 16.5mm |
| RL-Q02 | 2.5m3/h | G1 | 20mm |
- Filtration Accuracy
- 50 μm
- Water Type
- tap water
- Suitable Water Pressure
- 0.1-0.6MPa
Performance
System Performance
1.5 m3/h
Rated Flow Rate (RL-Q01)
2.5 m3/h
Rated Flow Rate (RL-Q02)
