ASTM Gate Valve
Gate valves control the flow of liquids and gases in pipelines. These valves are manufactured to ASTM standards and come in sizes from 2 to 8 inches.
Technical Specifications
Product Overview
Industrial ASTM Gate Valve
This industrial-grade gate valve is manufactured in strict accordance with ASTM standards to ensure reliability and performance in demanding applications. Constructed from durable materials including stainless steel, aluminum bronze, and cast bronze, it is engineered to meet rigorous pressure and design specifications. Designed for versatility, this valve is available in a wide range of sizes from 1/2" to 8" to suit diverse piping infrastructure requirements.
Compliance & Standards
- Standards & Certifications
- ASTM B16.34ANSI B16.34MSS-SP-70API 600API 598ANSI B16.10
Material Specifications
Available Materials
Stainless SteelAluminum BronzeCast Bronze
Technical Dimensions
Size and Weight Specifications
| Size | Approx. Weight (lbs) | Approx. Weight (kgs) |
|---|---|---|
| 1/2" | 2.5 | 1.1 |
| 3/4" | 2.5 | 1.1 |
| 1" | 60 | 4.5 |
| 1-1/4" | 65 | 5 |
| 1-1/2" | 65 | 5 |
| 2" | 65 | 6 |
| 2-1/2" | 90 | 12 |
| 3" | 90 | 12 |
| 4" | 115 | 25 |
| 5" | 135 | 44 |
| 6" | 135 | 55 |
| 8" | 160 | 88 |
