Aluminum Pulley Water Pump
This aluminum pulley water pump is designed for efficient fluid transfer. It features a pulley drive system, offering flexible integration with various power sources for diverse applications.
Technical Specifications
Product Overview
High-Efficiency Pulley Pump
The SU series pulley pump is a robust fluid transfer solution engineered for demanding agricultural irrigation and industrial drainage applications. Featuring a durable aluminum alloy body paired with a cast iron impeller, this pump is designed for reliable performance and longevity. Its pulley-driven system allows for flexible integration with various gasoline engines, making it a versatile choice for diverse operating environments.
Performance Metrics
Flow Rate
96 m3/h
Flow
- Lift Head
- 27 m
- Suction Head
- 7 m
Technical Specifications
- Model
- SU-100
- Inlet/Outlet Size
- 4 inch
- Speed
- 3600 rpm
- Matched Power
- 9/13 hp
Physical Dimensions
- Overall Dimensions
- 360 x 295 x 285 mm
Construction
- Material Composition
- Aluminum Alloy BodyCast Iron Impeller
Usage Guidelines
Operating Notes
- Prime the pump with water before running to prevent damage
- Do not run dry
