Aluminum Alloy Mechanical Connector
This mechanical connector is used for intermediate connections of copper, aluminum, and aluminum alloy cables at low voltage. It features torque-controlled shear head bolts that ensure stable working performance without conductor damage.
Technical Specifications
Product Overview
High-Performance Mechanical Connector
The SCLL series mechanical connector provides a reliable, high-strength solution for the intermediate connection of copper, aluminum, and aluminum alloy cables in low-voltage systems. Designed for ease of installation, it features shear-off bolt technology that ensures stable electrical performance without the need for specialized crimping tools. The connectors arrive prefilled with jointing compound and feature a durable tin-plated aluminum alloy body to ensure superior conductivity and mechanical integrity in various power network applications.
Technical Specifications
Installation Features
- No crimping tools required (use socket spanner or wrench)
- Torque-controlled shear head bolts
- Prefilled with jointing compound
- Threaded inner surface for enhanced performance
Product Range Table
| Model | AL Range (mm²) | Bolts | Torque (Nm) |
|---|---|---|---|
| SCLL1.5-16/2S | 1.0-16 | 2 | 3 |
| SCLL1.5-16/2L | 1.0-16 | 2 | 3 |
| SCLL6-25/2L | 6-35 | 2 | 5 |
| SCLL6-50/2L | 6-50 | 2 | 11 |
| SCLL16-95/2L | 16-95 | 2 | 20 |
| SCLL25-150/2L | 25-150 | 2 | 34 |
| SCLL50-240/4L | 50-240 | 4 | 35 |
- Material Composition
- High strength aluminum alloy bodyAluminum alloy boltsTin-plated surface
Standards and Compliance
- Standards
- IEC 61238-1:2003
