All-Terrain Forklift
This heavy-duty forklift is designed for agricultural and construction applications. It features a robust chassis, high lifting capacity, and all-terrain tires for optimal performance in various environments.
Technical Specifications
Overview
Robust All-Terrain Performance
This all-terrain forklift is engineered for demanding agricultural and construction environments. Featuring a robust chassis and high-flotation tires, it delivers reliable performance across uneven surfaces while maintaining a 2000kg lifting capacity. The unit includes an enclosed cabin designed for operator comfort and safety, ensuring productivity in diverse working conditions.
Performance Metrics
Rated Load Capacity
2,000 kg
Rated Load
- Travel Speed
- 18 km/h
- Turning Radius
- 4800 mm
Technical Specifications
Engine Details
| Attribute | Value |
|---|---|
| Engine Model | Xinchai 490 |
| Power Output | 32 kW |
Dimensions & Clearance
- Wheelbase: 2050mm
- Ground Clearance: 230mm
- Mast Tilt Angles
- Rear: 6ºFront: 12º
- Total Machine Weight
- 3980 kg
- Tire Specification
- 12-16.5
