Air-Cooled 1.2kW Diesel Generator
This air-cooled diesel generator is designed for efficient power generation. It features a compact design and is ideal for applications requiring a reliable power source.
Technical Specifications
Overview
High-Performance Diesel Power Generation
This air-cooled 1.2kW diesel generator is engineered for efficiency and reliability, featuring advanced fuel pump technology and a high-burning rate combustor for superior fuel economy compared to gasoline alternatives. Its robust vertical, two-cylinder design ensures compact construction with large displacement and high output. Designed with a focus on durability and safety, the unit includes a well-designed gear transmission structure to minimize noise and vibration, making it a versatile power solution for various professional applications.
Technical Specifications
Power Output
1.2 kW
Power Output
12 V
Voltage Rating
Engine Configuration
| Feature | Detail |
|---|---|
| Cooling System | Air-cooled |
| Cylinder Configuration | Vertical, V-type two-cylinder |
| Model Designation | HV12-1 |
| Starter Type | Gear motor |
Operational Guidelines
Fuel & Lubrication
- Summer: 0# Diesel
- Winter: -10# or -20# Diesel
- Lubrication Oil: Classification CC or CD
- Initial Run Requirements
- During the first 20 hours of operation, run the engine at lower speed and lower load to ensure optimal performance and longevity.
Safety & Compliance
- Safety Compliance
- Flammable Fuel HandlingOutdoor Use OnlyCarbon Monoxide HazardFire Hazard Prevention
