AC/DC Convertible Water Pump
This AC/DC convertible pump can be powered by either standard AC or DC power sources. Its energy-efficient design reduces power consumption while maintaining optimal performance.
Technical Specifications
Overview
High-Efficiency AC/DC Convertible Pump
This advanced water pump features permanent magnetic technology, offering 10-15% energy savings compared to standard models. Designed for versatility, it operates across a wide voltage range and can be powered by both AC and DC sources, including solar panels. With intelligent monitoring and multiple safety protections, it provides reliable performance for industrial and commercial water circulation and pressure boosting applications.
Performance Metrics
Key Performance Indicators
3,620 r/min
Rotational Speed
52 m
Maximum Head
Electrical Specifications
- AC Voltage Range
- 140V - 270V
- DC Voltage Range
- 200V - 380V
Smart Features & Protection
Integrated Protections
- Dry running protection
- Lock-up protection
- Undervoltage protection
- Overvoltage protection
- Automatic pressure-based stop
System Error Codes
| Condition | Code |
|---|---|
| Dry Running | 55 |
| Lock Up | 01 / 02 |
| Undervoltage | 04 |
| Overvoltage | 08 |
| Pressure Limit Reached | 33 |
Construction & Materials
- Material Composition
- Brass ImpellerHigh-Strength Cast Iron/Aluminum BodyImported Bearings
Certifications
Compliance Standards
CEISO 9001RoHSCSA
