71.4V 7A Lithium-Ion Battery Charger for Electric Scooters
This lithium-ion battery charger is designed for electric motorcycles and scooters. It delivers 71.4V and 7A, optimized for 17S 60V battery packs.
Technical Specifications
Overview
Reliable Power for Electric Mobility
This high-performance battery charger is engineered for consistent power delivery to electric motorcycles, scooters, and e-bikes. Constructed with a durable aluminum alloy casing and an integrated cooling fan, it ensures efficient heat dissipation and long-term reliability. It is a versatile solution compatible with lithium-ion, LiFePO4, and lead-acid battery chemistries.
Technical Specifications
Compatible Battery Types
- Li-ion
- LiFePO4
- Lead Acid
- Output Power
- 500 W
- Output Voltage & Current
- 71.4V / 7A
- Input Voltage Range
- 110-132VAC200-264VAC
Physical Characteristics
- Dimensions
- 173 x 90 x 63 mm
- Net Weight
- 1.1 kg
- Housing Material
- Aluminium Alloy
Operational Features
LED Indicator Guide
| Status | Indication |
|---|---|
| No Battery Connected | Alternating Red/Green |
| Charging | Flashing Red |
| Trickle Charging | Flashing Green |
| Fully Charged | Solid Green |
Compliance & Support
Certifications
CE
- Warranty
- 12 Months
