6mm Mini LED Indicator Light for Elevators
This 6mm mini LED indicator light is designed for elevator panels. It provides clear visual indication of equipment status with its energy-efficient LED technology.
Technical Specifications
Overview
High-Performance Mini LED Indicators
The AD22 series LED indicators are engineered to replace traditional incandescent and neon lamps with high-brightness LED chips. These compact 6mm pilot lights offer low power consumption, exceptional reliability, and a long service life, making them ideal for space-constrained panels. Designed with polycarbonate lampshades for high intensity and anti-surge performance, they provide clear visual signaling for elevators, telecommunications, and industrial machinery.
Key Metrics
Featured Specifications
6 mm
Mounting Diameter
2.5 kV
Working Freq. Voltage
2 MΩ
Insulation Resistance
Technical Parameters
Safety & Construction
- Polycarbonate high-intensity lampshade
- Anti-surge performance
- Bolt-type connector for secure wiring
- Integrated resistor and diode circuit
- Available Voltages
- 6V AC/DC12V AC/DC24V AC/DC36V AC/DC48V AC/DC110V AC/DC127V AC/DC220V AC/DC380V AC
- Voltage Wave Allowance
- ±20%
Physical Characteristics
Available Colors
RedGreenYellowBlueWhite
Mechanical Dimensions
| Parameter | Value |
|---|---|
| Mounting Diameter | 6mm |
| Body Diameter | 6.5mm |
| Flange Thickness | 2mm |
| Max Thread Length | 10mm |
| Total Length | 21mm |
Application & Usage
Target Industries
- Elevator Control Panels
- Electrical Power Equipment
- Telecommunication Systems
- Machine Tools
- Textile & Printing Machinery
- Mining Equipment
Model Configuration
Model Suffix Meanings
| Code | Description |
|---|---|
| L | Equipped with cables |
| C | Fast-connect terminals |
| S | Short base design |
| No Letter | Long base design |
