67.2V 5A Lithium Battery Charger for Electric Scooters
This lithium battery charger is designed for electric scooters and motorcycles. It provides a 67.2V output at 5A, suitable for charging 16S 60V battery packs.
Technical Specifications
Overview
High-Performance Charging Solution
This versatile battery charger is engineered for reliable performance in electric mobility applications, including e-bikes, scooters, and electric motorcycles. Featuring a robust aluminium alloy construction and a 400W power output, it is designed to support various battery chemistries such as Li-ion, LiFePO4, and lead-acid. With universal input voltage capabilities and a compact, lightweight form factor, this unit offers a flexible and efficient charging solution for professional and personal use.
Technical Specifications
Input Voltage Range
- 110-132VAC
- 200-264VAC
Output Performance
67.2 V
Output Voltage
5 A
Output Current
400 W
Output Power
- Compatible Battery Types
- Li-ionLiFePO4Lead Acid
Physical & Design
- Dimensions
- 137 x 90 x 51 mm
- Net Weight
- 1 kg
- Housing Material
- Aluminium Alloy
Compliance & Usage
Certifications
CE
- Warranty
- 12 Months
- Primary Applications
- Electric MotorcycleScooterE-bike
