67.2V 3A Lithium-Ion Battery Charger for Electric Scooters
This lithium-ion battery charger is designed for electric motorcycles and scooters. It operates at 67.2V and provides a 3A charging current, suitable for 60V and 12S battery configurations.
Technical Specifications
Overview
Reliable Power for Electric Mobility
This high-performance battery charger is engineered for efficient power delivery to electric motorcycles, scooters, and e-bikes. Designed with a robust aluminium alloy casing, it provides versatile charging support for lithium-ion, LiFePO4, and lead-acid battery systems. With a 300W output and smart LED status indicators, it ensures safe and consistent performance for your electric vehicle fleet.
Technical Specifications
Output Performance
300 W
Output Power
67.2 V
Output Voltage
3 A
Output Current
- Input Voltage Range
- 110-132VAC / 200-264VAC
- Supported Battery Types
- Li-ionLiFePO4Lead Acid
Physical & Build
- Dimensions
- 137 x 90 x 51 mm
- Net Weight
- 1 kg
- Casing Material
- Aluminium Alloy
Features & Safety
LED Status Indicators
| Status | Indicator |
|---|---|
| No Battery Connected | Green Flashing |
| Charging | Red Light |
| Fully Charged | Green Light |
| Error/Alarm | Red Flashing |
Certifications
CE
Compatible Applications
- Electric Motorcycle
- Electric Scooter
- E-bike
- Warranty
- 12 Months
