6-Cylinder Diesel Engine for Generators
This is a large power, 6-cylinder diesel engine designed for generator sets. It features direct injection combustion for easy starting and low fuel consumption.
Technical Specifications
Product Overview
High-Performance 6-Cylinder Diesel Engine
This vertical, in-line 6-cylinder diesel engine is specifically engineered for heavy-duty generator sets and industrial applications. Featuring a direct injection combustion chamber, it ensures easy starting and superior fuel economy for professional operations. The engine utilizes a turbocharged and inter-cooled intake system to deliver reliable, high-power performance in demanding environments.
Core Performance
Performance Ratings
180 kW
Max Standby Power
1,500 r/min
Rated Speed
7.98 L
Displacement
Technical Specifications
- Model
- QC6112ZLD
- Engine Configuration
- Vertical, in-line, water-cooled, four-stroke, turbocharged and inter-cooled
- Bore & Stroke
- 6-112 x 135 mm
- Cylinder Liner Type
- Wet
- Intake Way
- Turbocharged and inter-cooled
Operating Efficiency
Fuel and Speed Performance
| Speed (r/min) | Fuel Consumption Ratio (g/kW·h) |
|---|---|
| 1,500 | ≤ 198 |
| 1,800 | ≤ 196 |
Mechanical Interface
Housing & Flywheel
- Flywheel cover type: SAE2#
- Flywheel type: SAE11.5"
- Smooth speed rate: ≤ 5%
Key Features
- Advantages
- Direct InjectionLow Fuel ConsumptionEasy StartTurbochargedWater-CooledIndustrial Grade
