5900N.m Pneumatic Clutch
This pneumatic clutch delivers 5900N.m of torque. It is suitable for use in machinery such as vacuum pumps.
Technical Specifications
Product Overview
ZQL Axial Pneumatic Clutch
The ZQL axial pneumatic clutch is a specialized, patented solution designed as a direct, high-performance replacement for manual clutches. Featuring a compact and lightweight design, it allows for direct mounting on motor shaft extensions or reducer input shafts, supporting remote operation. This versatile transmission mechanism is engineered to deliver reliable torque transmission across a wide range of industrial applications, including oil drilling, forging machinery, and brick and tile production.
Technical Specifications
Rated Torque
5,900 N.m
Torque Capacity
Compatible Gearboxes
- Standard JZQ Reducer
- Non-standard Gearboxes
Torque Range Availability
| Torque Range (N.m) |
|---|
| 650 |
| 2,700 |
| 5,900 |
| 8,500 |
| 12,000 |
| 13,000 |
| 16,500 |
| 19,500 |
- Available Types
- Diaphragm TypePiston Type
Performance Features
Diaphragm Type Benefits
- Compact structure
- Light weight
- Low inertia
- Good sealing performance
- Sensitive action
- Quick clutch response
Piston Type Benefits
- High torque capacity
- Large wear compensation for friction plates
Applications
Primary Industries
Oil DrillingForging MachineryBrick and Tile IndustryFishing Machinery
