58.8V 4A Lithium-Ion Battery Charger for Electric Scooters and Motorcycles
This lithium-ion battery charger is engineered for electric motorcycles and scooters. It provides a 58.8V output at 4A, optimized for charging 4S 48V battery packs.
Technical Specifications
Overview
Professional Battery Charging Solution
This high-performance battery charger is engineered specifically for electric motorcycles, scooters, and e-bikes. Designed with a robust aluminium alloy housing, it provides reliable and efficient power delivery to ensure optimal battery health and longevity. The unit supports versatile input voltages and includes comprehensive LED status indicators for safe, user-friendly operation.
Technical Specifications
Compatible Battery Types
Li-ionLiFePO4Lead Acid
- Output Power
- 300 W
- Output Voltage
- 58.8 V
- Output Current
- 4 A
- Input Voltage Range
- 110-132VAC200-264VAC
Physical Characteristics
- Dimensions
- 137 x 90 x 51 mm
- Net Weight
- 1 kg
- Housing Material
- Aluminium Alloy
Operation & Safety
LED Status Indicators
| Status | Indicator |
|---|---|
| No Battery Connected | Flashing Green |
| Charging in Progress | Solid Red |
| Fully Charged | Solid Green |
| Error/Alarm | Rapidly Flashing Red |
Primary Applications
- Electric Motorcycles
- Electric Scooters
- E-bikes
- Certifications
- CE
- Warranty
- 12 Months
