58.4V 20A LiFePO4 Battery Charger for E-Bike/Motorcycle/Scooter
This battery charger is designed for 16S LiFePO4 battery packs commonly found in electric bikes, motorcycles, and scooters. It provides a regulated 58.4V output at 20A and includes LED indicators for charging status.
Technical Specifications
Product Overview
High-Performance 16S LiFePO4 Charger
This C1200 series battery charger is engineered for reliable, high-speed charging of 16S LiFePO4 battery packs. With a robust 1168W output power and a 20A current, it is optimized for demanding applications including electric bikes, scooters, motorcycles, and cleaning equipment. The unit features an industrial-grade aluminium alloy shell and is fully CE certified, ensuring safety and durability in professional environments.
Electrical Specifications
- Output Power
- 1168 W
- Output Voltage
- 58.4 V
- Output Current
- 20 A
- Input Voltage Range
- 110-132VAC / 200-264VAC
- Compatible Battery Configuration
- 16S LiFePO4
Physical & Mechanical
- Dimensions
- 264 x 120 x 89 mm
- Net Weight
- 2.1 kg
- Housing Material
- Aluminium Alloy
Compliance & Support
- Warranty
- 12 Months
- Certifications
- CE
Application
Suitable Applications
- Electric Bikes
- Electric Motorcycles
- Electric Scooters
- Cleaning Equipment
- Golf Carts
