54.6V 9A Lithium-Ion Battery Charger for Electric Scooters
This lithium-ion battery charger is designed for electric motorcycles and scooters. It provides a 54.6V charging voltage and 9A current for 13S 48V battery packs.
Technical Specifications
Overview
High-Performance Charging Solution
This 500W lithium-ion battery charger is engineered for electric motorcycles, scooters, and e-bikes. Housed in a durable aluminum alloy casing, it features active cooling for efficient heat dissipation during operation. It supports a wide range of battery chemistries, including Li-ion, LiFePO4, and lead-acid, making it a versatile choice for various electric mobility applications.
Electrical Specifications
- Output Voltage
- 54.6 V
- Charging Current
- 9 A
- Input Voltage Range
- 110-132VAC / 200-264VAC
- Output Power
- 500 W
Physical Attributes
- Dimensions
- 173 x 90 x 63 mm
- Net Weight
- 1.1 kg
- Housing Material
- Aluminium Alloy
Compatibility & Usage
Applications
Electric MotorcycleScooterE-bike
- Supported Battery Types
- Li-ionLiFePO4Lead Acid
- Socket Standard
- Customizable to destination country
Compliance & Warranty
Certifications
CE
- Warranty Period
- 12 Months
