54.6V 18A Lithium-Ion Battery Charger for E-bikes
This battery charger is designed for charging 13S Li-ion battery packs commonly found in e-bikes, motorcycles, and scooters. It features LED indicators to display charging status, with red indicating charging and green indicating a full charge.
Technical Specifications
Overview
High-Performance 13S Li-ion Charger
This C1200 series battery charger is engineered for reliable and efficient charging of 13S Lithium-ion battery packs. Designed with a durable aluminum alloy shell, it provides consistent power output for demanding applications including electric bikes, motorcycles, and scooters. With a focus on safety and compliance, this unit features CE certification and robust thermal management.
Electrical Specifications
- Input Voltage Range
- 110-132VAC / 200-264VAC
- Output Voltage
- 54.6 V
- Output Current
- 18 A
- Output Power
- 982.8 W
- Compatible Battery Type
- 13S Li-ion
Physical Characteristics
- Dimensions
- 264 x 120 x 89 mm
- Net Weight
- 2.1 kg
- Casing Material
- Aluminium Alloy
Usage & Compliance
Certifications
CE
- Applications
- E-bikeMotorcycleScooterCleanerGolf Cart
- Warranty Period
- 12 Months
