43.8V 20A LiFePO4 Battery Charger for E-bikes
This battery charger is designed for 43.8V LiFePO4 batteries. It provides a reliable and efficient charging solution for electric vehicles such as e-bikes, motorcycles, and scooters.
Technical Specifications
Product Overview
High-Performance LiFePO4 Battery Charger
This C1200 series charger is engineered specifically for LiFePO4 battery systems, delivering a robust 876W of charging power. Designed for versatility and durability, it features an aluminum alloy shell for effective heat dissipation and is suitable for a wide range of electric mobility applications, including e-bikes, scooters, and golf carts. With its 20A output current and 12S configuration compatibility, it offers a reliable charging solution for professional and industrial use.
Technical Specifications
- Output Voltage
- 43.8 V
- Output Current
- 20 A
- Total Power
- 876 W
- Input Voltage Range
- 110-132VAC / 200-264VAC
- Compatible Battery Type
- LiFePO4
- Cells in Series
- 12
Physical Characteristics
- Dimensions
- 264 x 120 x 89 mm
- Net Weight
- 2.1 kg
- Shell Material
- Aluminium Alloy
Compliance & Support
- Certifications
- CE
- Warranty
- 12 Months
Applications
Suitable Applications
- Electric Bike
- Electric Motorcycle
- Electric Scooter
- Cleaning Equipment
- Golf Cart
Key Metrics
Performance Summary
876 W
Output Power
20 A
Output Current
12 S
Series Configuration
