42V 2A Lithium-Ion Battery Charger for 36V E-Bike/Scooter
This lithium-ion battery charger outputs 42V at 2A, suitable for charging 10S (10 series) 36V lithium-ion battery packs in electric bikes and scooters. It maintains a constant current/constant voltage (CC/CV) charging profile for optimal charging and battery longevity.
Technical Specifications
Product Overview
High-Efficiency 42V Lithium-Ion Charger
This XT8 model provides a reliable charging solution specifically engineered for 10S 36V lithium-ion battery packs. With a constant current/constant voltage (CC/CV) profile, it optimizes charging performance and supports battery longevity for e-mobility applications. Its wide-range input makes it highly versatile for international use, while the integrated LED status indicator keeps the user informed of charging progress.
Technical Specifications
Performance Metrics
42 V
Output Voltage
2 A
Output Current
84 W
Output Power
85 %
Efficiency
- Input Voltage Range
- 100-240VAC
Physical Attributes
- Dimensions
- 164 x 73 x 45 mm
- Net Weight
- 0.64 kg
- Material
- Plastic case
Compatibility & Usage
- Compatible Applications
- Electric MotorcycleElectric ScooterClean MachineE-bike
- Supported Battery Capacity
- 10Ah - 14Ah (10S 36V)
Operations
Charging Indicators
| Status | Indication |
|---|---|
| Charging | Red light |
| Fully Charged | Green light |
| 95% Charge Level | Flickering green light |
- Warranty Period
- 12 Months
