410-Ton High-Speed Injection Molding Machine
The GEK series high-speed injection molding machine is specialized for producing thin-wall PP products. It is widely used in the packaging industry.
Technical Specifications
Overview
High-Performance Thin-Wall Injection Solution
The GEK series high-speed injection molding machine is specifically engineered for the production of PP thin-wall products, making it an ideal choice for the high-demand packaging industry. With a robust 410-ton clamping force and rapid injection rates, this machine ensures consistent quality for complex plastic components. It combines precision control with high-volume throughput to meet the rigorous standards of professional manufacturing environments.
Key Performance Metrics
Performance Highlights
4,100 kN
Clamping Force
853 g/s
Injection Rate
166 MPa
Injection Pressure
Injection Unit
- Screw Diameter
- 52 mm
- Theoretical Shot Volume
- 551 cm3
- Injection Weight (PP)
- 397 g
- Plasticizing Capacity (PP)
- 42 g/s
Clamping Unit
- Mold Stroke
- 660 mm
- Space Between Tie Bars
- 670 x 660 mm
- Mold Thickness (Max/Min)
- 700 / 250 mm
Ejector System
Ejector Specifications
| Parameter | Value |
|---|---|
| Ejector Stroke | 110 mm |
| Ejector Force | 80 kN |
| Number of Ejectors | 13 pc |
Power & Hydraulics
- Pump Motor Power
- 50 + 50 kW
- Max Pump Pressure
- 16 MPa
- Heater Power
- 29.5 kW
Physical Dimensions
- Machine Dimensions (L x W x H)
- 7.5 x 1.9 x 2.5 m
- Machine Weight
- 16.8 t
Applications
- Target Applications
- Thin-wall PackagingPP ProductsHigh-volume ProductionComplex Components
