40ft Flatbed Semi-Trailer for Container Transport
This flatbed semi-trailer is designed for transporting 40-foot shipping containers. It features a robust steel frame and a multi-axle configuration for enhanced stability and weight distribution.
Technical Specifications
Overview
Heavy-Duty Container Transport Solution
This 40ft flatbed semi-trailer is engineered for the efficient and secure transport of standard shipping containers. Featuring a robust Q345B steel main beam construction, it offers high durability and weight-bearing capacity for professional logistics operations. With versatile axle configurations and premium braking components, this trailer ensures stability, safety, and reliability for long-haul freight requirements.
Dimensions & Capacity
- 40ft Load Capacity
- 45 T
- 40ft Trailer Dimensions
- 12450 x 2490 x 1557 mm
Chassis & Construction
Main Beam Plate Thickness
| Section | Thickness |
|---|---|
| Upper Plate | 14 |
| Middle Plate | 8 |
| Down Plate | 16 |
- Main Beam Material
- Q345B Steel
Running Gear
- Axle Load Capacity
- 13 T
- Suspension Options
- Mechanical SuspensionAir Suspension
Components
King Pin Size
- 2.0 inch
- 3.5 inch
Safety & Electrical
- Brake System Components
- WABCO Relay ValveSpring Brake ChamberABS Optional
- Voltage
- 24 V
