35 KVA Marine Diesel Generator
This marine generator is powered by a 2.4 liter turbocharged, 4-cylinder diesel engine. The compact and lightweight engine is optimized for low noise and vibration, making it suitable for boats and yachts.
Technical Specifications
Overview
Marine Diesel Generator
This 35 KVA marine generator is engineered for reliable power generation in maritime environments. Powered by a 2.4-liter, 4-cylinder turbocharged diesel engine, it is optimized for low noise and vibration, making it an ideal choice for boats and yachts. The unit includes integrated cooling systems, such as a sea water pump and heat exchanger, to ensure efficient operation and temperature control in engine rooms.
Engine Specifications
Emission Level
EU Stage IIIA
- Displacement
- 2.4 L
- Engine Type
- 4-cylinder turbocharged diesel
Performance Metrics
Rated Power (50Hz)
27.5 KVA
ESP
25 KVA
PRP
Rated Power (60Hz)
33 KVA
ESP
30 KVA
PRP
Technical Details
Sound Level @ 7m
- 58 dB(A) at 50 Hz
- 60 dB(A) at 60 Hz
- Phase Configuration
- 3P/4W
- Power Factor
- 0.8
Physical Dimensions
Physical Specifications
| Attribute | Value |
|---|---|
| Length | 1080 mm |
| Width | 650 mm |
| Height | 740 mm |
| Weight | 550 kg |
