3 HP Dust Collector with Table Turning
This 3 HP dust collector is designed for efficient dust collection in woodworking environments. It features a table turning over mechanism, enhancing its functionality and ease of use.
Technical Specifications
Overview
Versatile Dust Extraction Solution
This 3 HP dust collector is engineered for high-performance dust management in professional woodworking environments. Featuring a unique table-turning mechanism, the motor unit can be inverted to accommodate both standard floor-standing setups and wall-mounted extraction systems. Its robust design and dual-intake capacity make it an essential tool for maintaining air quality and safety in demanding industrial workshops.
Performance
Air Speed
1,160 m3/h
Air Speed
- Motor Power
- 2200 W
Technical Details
Inlet Configuration
- Main Inlet Diameter: 150mm
- Number of Intake Holes: 2 x 100mm
- Fan Diameter
- 305 mm
Dimensions & Weight
- Overall Dimensions (LxWxH)
- 1746 x 565 x 1890(1970) mm
- Net Weight
- 95 kg
- Packing Size
- 1753 x 610 x 680 mm
Filtration & Collection
Bag Specifications
| Type | Dimensions (mm) |
|---|---|
| Filter Bag | 500 x 850 |
| Collection Bag | 500 x 1100 |
Logistics
- 20ft Container Capacity
- 30 units
