29.2V 5A LiFePO4 Battery Charger for E-bikes
This battery charger is designed for LiFePO4 batteries, providing efficient charging for electric bikes, motorcycles, and scooters. It features a universal input voltage of 100-240VAC and LED indicators to display the charging status.
Technical Specifications
Product Overview
High-Efficiency LiFePO4 Charging Solution
The S120 charger is engineered for reliable and safe power delivery to 8S LiFePO4 battery systems. Housed in a durable aluminium alloy casing, this compact unit provides an efficient 146W power output. Designed for a wide range of electric mobility applications, it features clear LED status indicators to ensure optimal charging cycles.
Performance Specifications
Output Metrics
29.2 V
Output Voltage
5 A
Output Current
146 W
Output Power
- Input Voltage Range
- 110-132VAC / 200-264VAC
Physical & Compatibility
- Dimensions
- 137 x 90 x 51 mm
- Net Weight
- 0.8 KG
- Housing
- Aluminium Alloy
- Supported Equipment
- E-BikeElectric MotorcycleElectric ScooterCleanerGolf Cart
Certifications & Warranty
Regulatory Standards
CE Certified
- Warranty Coverage
- 12 Months
