250kVA Diesel Generator Set
This 250kVA diesel generator set delivers reliable power for various applications. It adheres to ISO and CE quality standards, ensuring high performance and durability.
Technical Specifications
Overview
High-Performance Diesel Generator Set
This 250kVA diesel generator set is engineered to provide reliable and stable power output for industrial, commercial, and residential applications. Featuring a robust 4-stroke engine and advanced electronic governor control, the unit ensures consistent performance with a fast start-up time of 5-6 seconds. Built to meet international quality standards, it includes a comprehensive air intake, exhaust, and cooling system designed for demanding operating conditions.
Key Metrics
Performance Highlights
250 kW
Prime Power
312.5 kVA
Prime Output
409 A
Rated Current
50 Hz
Frequency
Electrical Specifications
Electrical Data
| Parameter | Value |
|---|---|
| Rated Voltage | 400/230 V |
| Power Factor | 0.8 (Lag) |
| Start-up Time | 5-6 s |
| Insulation Class | H/H |
| Protection Class | IP23 |
Engine Specifications
Engine Configuration
| Feature | Specification |
|---|---|
| Cycle | 4 stroke |
| Cylinder Arrangement | 6 in line |
| Displacement | 11.906 L |
| Compression Ratio | 17:1 |
| Rated Speed | 1500 r/min |
| Governor Type | Electronic |
Standard Features
Included Components
- Radiator (50°C max)
- Belt-driven fan with safety guard
- 24V charge alternator
- Dry type air filter
- Fuel and oil filters
- Single bearing alternator
- Main line circuit breaker
- Standard control panel
- Vibration absorber
- Muffler
Compliance
- Quality Standards
- ISOCEEuro Stage II
