20L Dispersion Kneader for Rubber and Plastics
This 20L dispersion kneader is designed for efficient mixing and kneading of rubber and plastic compounds. It features a robust construction for thorough dispersion of additives and fillers.
Technical Specifications
Overview
High-Performance 20L Dispersion Kneader
This industrial-grade 20L dispersion kneader is engineered for the intensive mixing and kneading of rubber, plastics, and viscous compounds. Featuring advanced Taiwanese core technologies, the machine utilizes a chromium-coated mixing chamber for superior abrasion resistance and extended service life. Designed for efficiency, it offers precise control over mixing parameters, ensuring homogeneous dispersion and consistent material quality for demanding production environments.
Technical Parameters
Mixing Capacity
20 L
Capacity
- Productivity
- 15-40 KG/load
- Dimensions (H x W x L)
- 2,500 x 1,500 x 2,500 mm
- Total Weight
- 4500 KG
Power and Mechanics
Motor Power Ratings
| Component | Power |
|---|---|
| Driving Motor | 30 KW |
| Tilting Motor | 1.5 KW |
| Electric Heater | 4.0 KW |
- Tilting Angle
- 110 °
Design Features
Core Technologies
- Chromium-coated mixing chamber (0.12-0.18mm thickness)
- Exclusive rotor shaft sealing technology
- 42 chromium-molybdenum high-rigidity gear reducer
- Reverse rotation discharging for easy cleaning
- Dry mechanical shaft seal
- Available Chamber Types
- Tilting TypeLifting Type
