180 Degree Pneumatic Rotary Actuator
This pneumatic actuator is designed for 180-degree rotation in valve automation applications. It operates with an air supply pressure range of 0.25 to 0.8 MPa.
Technical Specifications
Overview
High-Performance Rotary Actuation
This double-acting rack and pinion pneumatic actuator is engineered for robust performance in demanding industrial environments. Featuring a versatile 180-degree rotation capability, it provides precise control for valve automation and various rotary motion applications. Built with advanced anti-corrosion technology and high-quality materials, this actuator ensures long service life and reliability in diverse operational settings.
Technical Specifications
- Rotation Angle
- 180 degrees
- Air Supply Pressure
- 0.25 - 0.8 MPa
- International Standards
- NAMURISO5211DIN3337
Construction & Materials
Surface Treatments
AnodizedEpoxyPTFENickel plated
- Body Material
- Die-cast aluminum (ASTM6005)
- Output Shaft Material
- Nickel plated alloy steel or stainless steel
- Fasteners
- Stainless steel
Features
Key Features
- Rack & pinion design for quick action
- Symmetrical installation for easy steering changes
- Antifriction sliding bearings
- Fine grinding process on inner surface
- Advanced anti-corrosion technology
