18 Ton Diesel Forklift Truck
This heavy-duty 18 ton diesel forklift truck is designed for demanding material handling applications. It features a robust chassis and a powerful diesel engine.
Technical Specifications
Overview
Heavy-Duty 18 Ton Diesel Forklift
This 18-ton diesel forklift is engineered for demanding industrial applications, offering a robust lifting capacity and high-torque performance. It features a high-quality turbocharged engine designed for energy conservation and environmental protection, paired with a full-hydraulic steering system for flexible and reliable operation. With a focus on operator efficiency, the truck includes a pilot valve control device and a full cab equipped with AC and a rear-view display.
Key Performance Metrics
Performance Highlights
18 t
Rated Load
900 mm
Load Center
3,500 mm
Lifting Height
30 km/h
Max Travel Speed
Engine & Powertrain
Engine Specifications
| Configuration | Power | Displacement | Cylinders |
|---|---|---|---|
| Standard Turbocharged | 129 KW @ 2200rpm | 6.494 L | 6 |
| High Performance Opt. | 142 KW @ 2200rpm | 6.7 L | 6 |
Chassis & Mobility
Tyre Configuration
- Front Tyres: 12.00-24-18PR (4 wheels)
- Rear Tyres: 12.00-20-18PR (2 wheels)
- Wheelbase: 3800 mm
- Front Wheel Tread: 2060 mm
- Rear Wheel Tread: 2330 mm
Operational Dimensions
Physical Dimensions
- Overall Length (with forks): 7640 mm
- Overall Width: 2750 mm
- Height to Cab: 3365 mm
- Mast Height (lowered): 3675 mm
- Fork Dimensions: 1800 x 220 x 100 mm
- Min. Turning Radius: 5800 mm
Technical Systems
- System Features
- Full-Hydraulic SteeringDisc BrakesPilot Valve ControlIndependent Oil CoolingBox-type FrameHydraulic Fork Positioner3D Finite Element AnalysisRear View Display
Operational Performance
Speed & Gradeability
| Metric | With Load | Without Load |
|---|---|---|
| Travel Speed | 26 km/h | 30 km/h |
| Lifting Speed | 250 mm/s | 260 mm/s |
| Gradeability | 20% | 21% |
Safety & Comfort
Operator Environment
- Full enclosed cab
- Air Conditioning (AC)
- Heating system
- Rear view monitoring display
- Ergonomic pilot control
Compliance & Quality
Standards & Certifications
ISO 9001:2015CE CertifiedGB/T 19001-2016Special Equipment License
