10kW Off-Grid Solar Power System
This 10kW off-grid solar power system utilizes solar energy to generate electricity for homes or businesses. It operates independently of the electrical grid, providing a sustainable and reliable power source.
Technical Specifications
Overview
10kW Off-Grid Solar Home System
This 10kW off-grid solar power system is a complete energy solution designed to convert solar radiation into reliable electrical energy using high-efficiency photovoltaic technology. Ideal for residential or industrial applications in areas without grid access, it provides total energy independence through a robust combination of solar panels, a pure sine wave inverter, and a high-capacity battery bank. The system is engineered for durability and ease of use, featuring intelligent control technology to ensure a sustainable and stable power supply.
System Performance
System Capacity
Inverter Specifications
Inverter Features
- Double BRU intelligent control technology
- Pure sine wave AC output for all load types
- Imported IGBT module driver for high inductive load resistance
- Flexible Solar/Grid power priority modes
- Real-time LCD parameter display
- Intelligent fan cooling control
Energy Storage
Battery Bank Configuration
| Component | Specification |
|---|---|
| Battery Type | 12VDC / 200AH |
| Quantity | 20 PCS |
| Total Bank Voltage | 240VDC |
System Protection
- Safety Protections
- Output OverloadShort CircuitBattery Over-VoltageBattery Low-VoltageOver-Temperature (85℃)AC Charge Voltage Protection
Connectivity & Control
Communication Interfaces
Technical Specifications
- Solar Charge Controller
- 50 A
- Output Frequency
- 50 Hz
- Phase
- Single Phase
Installation & Logistics
- Packaging
- Export wooden case for transportation safety
