Technical Specifications
Product Overview
High-Efficiency Automatic Water Pump
The DCHZ series is a versatile, self-absorbing turbine pump engineered for both hot and cold water applications. Designed for high efficiency and reliability, this automatic electric pump is ideal for residential and light commercial water pressure boosting, irrigation, and general water transfer. Its durable construction ensures premium service and consistent performance for individual users.
Performance Metrics
Power Rating
0.5 HP
Horsepower
370 W
Power Output
Operational Capacity
40 l/min
Max Flow Rate
9 m
Max Suction Lift
Flow Rate vs. Head
| Flow (l/min) | Head (m) |
|---|---|
| 0 | 35 |
| 5 | 30 |
| 10 | 25 |
| 15 | 20 |
| 20 | 15 |
| 25 | 10.5 |
| 30 | 6 |
| 35 | 2 |
Construction & Materials
Material Composition
- Brass Impeller
- Aluminum Housing
- Iron Pump Body
- 100% Copper Winding
- Key Features
- Automatic ControlRust FreeSelf-AbsorbingHot & Cold Water Compatible
Technical Specifications
- Electrical Requirements
- 220V / 50Hz
Certifications & Compliance
Certifications
RoHSCEISO 9001CQC
