Vertical Grinding Mill for Minerals and Materials
The vertical grinding mill is a high-efficiency machine used across industries like cement, metallurgy, and chemical processing. It integrates crushing, drying, grinding, classifying, and conveying into a single unit for optimal performance.
Technical Specifications
Overview
High-Efficiency Vertical Grinding Solution
This vertical grinding mill integrates five critical industrial functions into a single, compact unit: crushing, grinding, powder selection, drying, and material conveying. Designed for optimized performance, it significantly reduces floor space requirements by approximately 50% compared to traditional ball-milling systems. The system operates under negative pressure within a sealed environment, ensuring environmental protection, stable operation, and minimal vibration during heavy-duty processing.
Technical Specifications
Processing Capacity
3 TPH
Minimum Capacity
340 TPH
Maximum Capacity
Integrated Functions
- Crushing
- Grinding
- Powder Selection
- Drying
- Material Conveying
- Input Material Size
- 0-70mm
Application & Materials
Target Industries
CementPowerMetallurgyChemicalConstruction
- Suitable Materials
- LimestoneCalciteDolomitePetroleum CoalGypsumBariteMarbleTalcCoal Powder
Operational Features
System Benefits
- Compact layout (50% less space than ball mills)
- Low energy consumption
- Strong drying capacity
- Stable operation with low noise
- Easy grain size control
