Slot Die Coating Head
The slot die coating head is designed for applying liquid materials onto surfaces at room temperature or with heating. It is used in the production of surface films for circuit boards and other substrates like paper, fabrics, and plastics.
Technical Specifications
Product Overview
High-Precision Slot Die Coating System
This advanced slot die coating system is engineered for the uniform and controlled application of thin films onto a wide variety of industrial substrates. Featuring precise flow control and adjustable slot gap capabilities, it ensures consistent material distribution for demanding manufacturing processes. The system is available in two primary configurations: an ambient temperature model for circuit board surface films and a heated model suitable for diverse materials including fabrics, plastics, and specialized papers.
Technical Features
Available Configurations
- Type 1: Ambient temperature coating for circuit boards
- Type 2: Heated coating for paper, fabrics, and plastics
- Key Performance Features
- Uniform CoatingAdjustable Slot GapPrecise Flow ControlMulti-Manifold Design
Service and Support
Warranty and Service
Under standard operating conditions, all spare parts are eligible for free replacement within a one-year period. Please note that associated transportation and packaging fees for replacement parts are the responsibility of the customer.
