Semi-Automatic PET Blow Molding Machine
The SA series blow molding machine is a high output semi-automatic PET solution. It features automatic bottle discharging, a patented heating system, and automatic preform loading.
Technical Specifications
Overview
High-Efficiency Semi-Automatic PET Blow Molding
This series of semi-automatic PET blow molding machines is engineered for high-output production with reduced operator intervention. Featuring a patented heating system and automatic preform loading and bottle discharging units, these machines significantly lower labor requirements while maintaining high productivity. With configuration options supporting up to 6 cavities, they are capable of reaching outputs of up to 2800 bottles per hour, representing a substantial improvement over traditional manual molding processes.
Performance Metrics
Key Performance Metrics
2,800 BPH
Max Output
300 KN
Clamping Force
6 units
Max Cavities
Technical Specifications
Model Comparison
| Feature | MG-SA4 | MG-SA6 | MG-SA4 C |
|---|---|---|---|
| Cavities | 4 | 6 | 4 |
| Output (BPH) | 2000 | 2800 | 1800 |
| Clamping Stroke | 350mm | 250mm | 350mm |
| Mould Thickness | 190mm | 190mm | 300mm |
Container Capabilities
Container Specifications
- Material: PET
- Neck Diameter: 15-45mm
- Max Container Diameter: 70-110mm
- Max Container Height: 250-400mm
Electrical System
- Power Requirements
- 380V / 3PH / 50Hz
