Technical Specifications
Overview
High-Efficiency Nitrogen Generation
This advanced nitrogen generator utilizes Pressure Swing Adsorption (PSA) technology with carbon molecular sieves to deliver high-purity nitrogen gas. Designed for demanding industrial environments such as laser cutting, electronics, and food processing, it ensures reliable performance and consistent gas quality. The system features an automated PLC-controlled valve cycle for efficient oxygen and nitrogen separation, providing a versatile solution for varied production requirements.
Performance Metrics
Key Performance Indicators
5,000 Nm3/h
Max Production Flow
0.8 Mpa
Max Working Pressure
-45 ℃
Dew Point
Technical Specifications
- Nitrogen Purity Range
- 95% - 99.9995%
- Voltage
- 220V/50HZ
- Core Components
- PLC
Quality & Standards
Certifications
ISO9001CE
Inspection Support
- Machinery Test Report Provided
- Video Outgoing Inspection Provided
- Core Component Warranty
- One Year
Model Selection Table
Model Specifications
| Model | Purity | Flow (Nm3/h) |
|---|---|---|
| WE-N2 97 | 97% | 5-3000 |
| WE-N2 98 | 98% | 4-2500 |
| WE-N2 99 | 99% | 3-2100 |
| WE-N2 295 | 99.5% | 2-1800 |
| WE-N2 39 | 99.9% | 1.5-1300 |
| WE-N2 49 | 99.99% | 1-800 |
| WE-N2 495 | 99.995% | 1-750 |
| WE-N2 59 | 99.999% | 0.5-500 |
| WE-N2 595 | 99.9995% | 0.5-400 |
