Multifunctional Wheel Skid Steer Loader
This multifunctional wheel skid steer loader features a small, flexible body and high passability. It can operate in extreme conditions and can be hoisted to the top of buildings with a crane.
Technical Specifications
Overview
Compact and Versatile Performance
This multifunctional wheel skid steer loader is engineered for high maneuverability and efficiency in demanding work environments. With a compact fuselage, it easily navigates tight spaces and is light enough for crane hoisting to elevated work sites. Designed for reliability, this machine delivers consistent performance across construction, landscaping, and agricultural applications.
Performance Metrics
Load Capacity
750 kg
Load
1,653.5 lb
Load
Gross Weight
3,003 kg
Gross Weight
6,620.5 lb
Gross Weight
Engine & Power
Engine Configuration
| Feature | Detail |
|---|---|
| Engine Model | 498BPG |
| Type | Four cylinder, water cooling, four stroke |
| Rotating Speed | 2500 r/min |
| Power Output | 45 kW (60 HP) |
Technical Specifications
Operational Data
- Travel Speed: 12 km/h (7.5 mile/h)
- Tire Size: 10-16.5
- Hydraulic Pump Flow (Working): 65 L/min
- Fuel Tank Capacity: 88 L (19.36 UK gal)
- Hydraulic System Components
- High Torque Motor (398cc)Tandem Plunger Pump (44cc)
