Modular Plastic Conveyor Belt with Friction Top
This modular plastic conveyor belt features a rounded friction top surface for enhanced grip. Constructed from durable plastic, it is resistant to wear, chemicals, and temperature variations.
Technical Specifications
Overview
High-Performance Modular Conveyor Belt
This rounded friction top modular plastic conveyor belt is engineered for demanding material handling environments, including inclined or declined systems. Its modular construction facilitates easy assembly, maintenance, and customization to specific conveyor dimensions. Built from durable, high-density materials, it offers exceptional resistance to wear, chemicals, and temperature fluctuations, ensuring reliable performance in both food and non-food industrial applications.
Technical Specifications
Core Dimensions & Properties
| Property | Value |
|---|---|
| Pitch | 50.8mm |
| Thickness | 19.5mm |
| Minimum Width | 203mm |
| Open Area | 0% |
| Rod Diameter | 5.8mm |
Performance & Compatibility
Performance Metrics
1.2 tons/m²
Max Load Capacity
260 °C
Max Temperature
-40 °C
Min Temperature
Compliance
FDA ApprovedEU Compliant
- Available Materials
- PPPOMPEPA
System Integration
Compatible Sprocket Sizes
- 6T
- 8T
- 10T
- 12T
- 6T-N
- 8T-N
- 10T-N
- 12T-N
- Bore Types
- Square BoreRound Bore
Applications
Industries Served
- Meat Processing (Beef & Pork)
- Poultry
- Seafood
- Bakery
- Snack Food
- Fruit & Vegetables
- Automotive
- Tire Manufacturing
- Packaging
- Printing & Paper
- Postal Services
- Corrugated Cardboard
- Can Manufacturing
- PET Manufacturing
- Textile
