Mixed Flow Ventilation Fan 100mm Duct
This mixed flow fan is designed for efficient ventilation. Its mixed flow impeller combines axial and centrifugal characteristics for high airflow and static pressure.
Technical Specifications
Overview
High-Efficiency Ventilation
The DPT-100P Mixed Flow Ventilation Fan is engineered for optimal air movement, combining the high airflow of axial fans with the static pressure capabilities of centrifugal designs. This unit is built for durability and reliable performance in residential, commercial, and industrial ventilation systems. Designed for easy installation, its compact 100mm duct size allows for flexible placement in confined spaces while maintaining low noise levels.
Technical Specifications
Ingress Protection
IPX2
- Duct Diameter
- 100 mm
- Rated Voltage
- 220V
- Power Consumption
- 28 W
Performance Metrics
Core Performance Metrics
2,200 r/min
Fan Speed
275 m³/h
Airflow
163 Pa
Static Pressure
Features
Key Benefits
- Low noise operation
- Long service life
- Mixed flow impeller design
- High static pressure capability
- Compact and easy to install
