Large Diameter Slewing Bearing
This large diameter slewing bearing is designed for heavy-duty applications. It features precision-engineered raceways and robust construction for optimal load distribution and smooth rotation.
Technical Specifications
Overview
High-Performance Large Diameter Slewing Bearing
These large diameter slewing bearings are engineered for heavy-duty industrial applications, offering robust load distribution and smooth rotational movement. Constructed from high-quality steel materials, these bearings are suitable for demanding environments like cranes, excavators, and wind turbines. The precision-machined raceways and flexible gear options ensure reliable performance across international standards.
Dimensions
Size Specifications
5,000 mm
Max Outer Diameter
5,000 mm
Max Inner Diameter
300 mm
Max Width
Technical Specifications
Hardness Specifications
| Component | Hardness Range |
|---|---|
| Normalizing | 187HB-241HB |
| Quench & Temper | 229HB-269HB |
| Raceway (Post-Quench) | 55HRC-62HRC |
Gear Configuration
- External gears
- Internal gears
- No gears
- Ring Materials
- 42CrMo50MnSteel 45#
- Rolling Element Material
- Chrome steel GCr15 or GCr15SiMn
