Industrial Robotic Arm
This industrial robotic arm is widely used in burnishing and polishing applications. It is also suitable for machine loading/unloading and automated transport on punching automation production lines.
Technical Specifications
Overview
Industrial Robotic Arm Series
This series of high-performance industrial robotic arms is engineered for versatility and precision in demanding manufacturing environments. Designed for applications such as burnishing, polishing, machine loading/unloading, and automated transport, these units feature a robust 6-axis configuration and a reliable AC servo drive system. With multiple reach options and consistent repeatability, they offer a scalable solution for integrating automation into punching production lines and assembly workflows.
Technical Specifications
Model Comparison
| Specification | RB08A3-1490 | RB08A3-1700 | RB08A3-1840 |
|---|---|---|---|
| Payload (kg) | 8 | 8 | 6 |
| Motion Radius (mm) | 1490 | 1700 | 1840 |
| Machine Weight (kg) | 185 | 187 | 180 |
| Repeatability (mm) | ±0.05 | ±0.05 | ±0.05 |
- System Configuration
- 6-DOF ConfigurationAC Servo Drive System
Performance Metrics
Top Velocity (J1-J3)
200 °/s
J1-J3 Velocity (1490 Model)
180 °/s
J1-J3 Velocity (1700 Model)
160 °/s
J1-J3 Velocity (1840 Model)
Applications
Primary Applications
- Burnishing
- Polishing
- Machine loading/unloading
- Automatic transport
- Punching automation production lines
