Fan Filter Unit for Cleanrooms
Fan filter units provide terminal air filtration. Air is drawn in through a fan and filtered through a HEPA filter to supply clean air.
Technical Specifications
Overview
High-Efficiency Fan Filter Unit (FFU)
This Fan Filter Unit (FFU) is an advanced air purification solution designed for cleanroom environments. It integrates a high-performance fan with a HEPA filtration module to deliver consistently clean air at a uniform velocity of 0.45m/s. Engineered for durability and energy efficiency, this unit features a modular design suitable for diverse applications, from clean production lines to large-scale cleanroom facilities.
Technical Specifications
Air Velocity
0.45 m/s
Rated Air Velocity
- Unit Dimensions
- 1175 x 575 x 340 mm
- Noise Level
- 50 dB
- Expected Service Life
- 50000 hours
Construction & Materials
Key Design Features
- Detachable filter and box design
- Direct driving centrifugal fan
- Modular configuration
- Uniform air flow passage
- Construction Materials
- Mirror Stainless SteelAluminum AlloyCold-rolled Steel
Performance & Compliance
Supported Cleanliness Levels
Class 10Class 100Class 1000
Control & Monitoring
- Central computer monitoring system
- Digital adjustment
- High energy-saving capability
- Quality Testing Standard
- US 209E
