Excavator Rubber Track
These rubber tracks are made with high standard natural and synthetic rubber and iron core. The jointless steel cord production technology ensures durability for challenging road conditions.
Technical Specifications
Product Overview
High-Performance Rubber Tracks
Engineered for excavators, skid steer loaders, and dumpers, these rubber tracks utilize high-standard natural and synthetic rubber materials reinforced with jointless steel cord technology. This construction ensures superior durability and reliable performance even in the most challenging construction environments. The specialized design provides optimal traction, enhanced stability, and reduced vibration for efficient operation across various terrains.
Key Features
- Construction Features
- Jointless Steel CordWear-Resistant RubberHigh Tensile StrengthRobust Iron CoreOptimized Tread Pattern
Technical Specifications
Operating Metrics
500 KG
Minimum Load Capacity
16,000 KG
Maximum Load Capacity
28
Minimum Tooth Count
118
Maximum Tooth Count
Available Range
- Widths from 150mm up to 800mm
- Pitch options ranging from 47K to 150mm
- Tread patterns: CA, TA, IB, IA, CB, AA, GA, CF, BC, JA, JB, DA, CD, BB, BA, AB, DC, MA, NB, etc.
- Roller types A through F
