Enameled Water Heater Tank with Single Weld Line
This water heater tank is made with SPCC plates and formed with a single weld line. It features a wet enamel coating.
Technical Specifications
Product Overview
Engineered for Durability
This enameled water heater tank is engineered with exclusive single weld line technology, significantly reducing the number of weld joints to minimize leakage risks. Constructed from thickened SPCC plates, these tanks are built to withstand high-pressure working conditions, making them ideal for high-rise applications. The advanced wet enamel coating and double-firing process ensure superior longevity and corrosion resistance compared to standard industry tanks.
Technical Specifications
SPCC Plate Thickness
- 1.8mm
- 2.0mm
- 2.5mm
- Capacity Range
- 3 to 150 Liters
- Enamel Coating Thickness
- 0.38 - 0.5 mm
Manufacturing Process
Weld Technology
Single Weld LinePatented Technology
- Coating Process
- Wet Enamel Coating (Double Firing)
Performance Metrics
Leakage Risk Reduction
67 %
Leakage Risk Reduction
Weld Efficiency Comparison
| Metric | Single Weld Line Advantage |
|---|---|
| Weld Jointing | 1/2 of standard |
| Weld Line Number | 1/3 of standard |
| Weld Length | 1/4 of standard |
