Drawn Cup Needle Roller Bearing
Drawn cup needle roller bearings use cylindrical rollers to maintain separation between moving parts. The bearings have a high load carrying capacity and are suitable for applications where space is limited.
Technical Specifications
Overview
High-Performance Drawn Cup Needle Roller Bearings
These drawn cup needle roller bearings feature a thin-walled, deep-drawn outer ring designed to provide maximum load-carrying capacity in applications with limited radial space. By utilizing small-diameter cylindrical rollers, these bearings achieve a compact and lightweight profile without compromising on durability or performance. They are an ideal, cost-effective solution for managing high radial loads in automotive transmissions, gearboxes, and various industrial machinery.
Technical Features
Design Characteristics
- Thin-walled, deep-drawn outer ring
- High radial load carrying capacity
- Small radial section height
- Compact and lightweight construction
- Hardened raceway for rollers
Load Capability
High Radial LoadAxial Load Support (Combined Series)
Series & Models
Available Model Examples
| Open End Series (HK) | Closed End Series (BK) |
|---|---|
| HK0306TN | BK0306TN |
| HK0408TN | BK0408TN |
| HK0509 | BK0509 |
| HK0608 | BK0608 |
| HK0810 | BK0810 |
| HK1012 | BK1012 |
- Supported Series
- KNANKINAVNAOVRNAHKBK
Applications
Common Applications
- Automotive transmissions
- Vehicle engines
- Industrial gearboxes
- Power tools
- General rotary motion machinery
Product Configuration
End Configurations
- Open ends (open on both sides for easy lubrication)
- Closed ends (closed on one side)
- Roller Retention
- Cage-retained needle rollers for proper spacing and guidance
