Double Head Tube and Pipe Bending Machine
This double head bending machine is designed for the simultaneous bending of two ends of a workpiece. It ensures consistent bending accuracy and significantly reduces cycle times.
Technical Specifications
Overview
Precision Double Head Bending
This double head tube and pipe bending machine is designed for high-volume production, allowing for the simultaneous bending of two ends of a workpiece to significantly reduce cycle times. With robust construction and an integrated control system, it ensures consistent accuracy and durability for materials including steel, aluminum, and stainless steel. The machine features versatile operation modes and advanced safety systems, making it an ideal solution for the automotive, furniture, and construction industries.
Control & Operation
Operating Modes
- Hand-operated
- Auto
- Semi-circulation
- Full-circulation
Safety Features
Mobile foot switchAuto startEmergency stop
- Control System
- PLC TypeContact Digital Control
Technical Specifications
Bending Performance Metrics
185 °
Max Bending Angle
50 /sec
Bending Speed
14 MPa
Max Pressure
Machine Capacity Parameters
| Parameter | Model 38 | Model 42 |
|---|---|---|
| Max Bending Pipe Capacity | 38x2 | 42x2 |
| Bending Radius Region | 38-220 | 42-250 |
| Centre Region of Double Head | 170-1450 | 170-1450 |
| Oil Pump Capacity (L/min) | 17 | 22 |
- Oil Case Capacity
- 120 L
