Coffee Bean Color Sorting Machine with CCD Camera
This coffee bean color sorting machine uses a CCD camera to detect subtle color variations and identify defects. It ensures high-precision sorting to remove unwanted elements like dead, moldy, or burnt beans.
Technical Specifications
Product Overview
Advanced Coffee Bean Sorting Solution
This intelligent color sorting machine utilizes high-definition 5400-pixel CCD imaging technology to deliver precise separation of coffee beans. Designed for high-volume operations, it efficiently identifies impurities such as moldy, black, unhulled, or burnt beans and stones. With AI-driven photo capture and remote control capabilities, it ensures consistent quality and optimized throughput for both green and roasted coffee processing.
Key Technical Specifications
Performance Metrics
2 t/h
Max Output
99 %
Sorting Accuracy
650 kg
Machine Weight
- Physical Dimensions
- 1642 x 1670 x 1920 mm
- Model
- HS-C3
Imaging & Optical System
Imaging Capabilities
- High-definition scanning
- Color sorting
- Shape sorting
- Camera Resolution
- 5400 Pixels
- Light Source
- Advanced LED Optical Technique
Intelligent Features & Connectivity
- Smart Features
- AI Photo CaptureWifi ConnectivityMobile Control
- Remote Management Enabled
- Yes
Sorting Performance
Detected Impurities
Dead beansMoldy beansBlack beansUnhulled beansBurnt beansStones
