Centrifugal Fan for HVAC and Air Purification
This centrifugal fan is designed for HVAC and air purification systems. Its compact design and robust construction ensure efficient airflow and long-lasting performance.
Technical Specifications
Overview
High-Performance HVAC Centrifugal Fan
The YWFB280 is a professional-grade centrifugal fan engineered for demanding HVAC and air purification applications. Featuring a compact structure and a dynamically balanced metallic impeller, it delivers efficient airflow with low noise levels and high static pressure performance. Designed for long service life and easy installation, this fan is an ideal solution for ventilation units, industrial air purifiers, and commercial climate control systems.
Key Features
- Compact and robust structure
- Professional aerodynamic design
- Fine process control for durability
- High efficiency with low operational noise
- Long service life
- Easy installation and integration
Technical Performance
Performance Metrics (Model YWFB2E280)
1,900 m³/h
Max Air Flow
2,450 RPM
Rated Speed
67 dB(A)
Noise Level
Electrical Specifications
| Model | Voltage (V) | Freq (Hz) | Input Power (W) | Current (A) |
|---|---|---|---|---|
| YWFB2E280 | 230 | 50 | 190 | 0.85 |
| YWFB2E280H | 120 | 60 | 380 | 3.1 |
| YWFB4E280 | 230 | 50/60 | 102 | 0.46 |
Construction & Materials
- Impeller Material
- Galvanized steel for corrosion resistance
- Motor Technology
- External RotorDynamically BalancedHigh Efficiency
Applications
Primary Applications
HVAC SystemsAir PurificationMedical CentrifugesCommercial RefrigerationKitchen VentilationTrain Ventilation
Compliance & Quality
- Product Certifications
- VDEULCERoHSCCCISO 9001ISO 14001
Purchase Information
Ordering Process
- Style selection and requirement communication
- Design draft submission and detail confirmation
- Quotation and form validation
- Sample proofing and bulk production
- Quality inspection and secure packaging
