Centrifugal Fan for HVAC and Air Purification
This centrifugal fan is engineered for HVAC and ventilation systems, ensuring durability and efficient performance. The fan features a precision-balanced impeller for smooth operation and reduced noise levels.
Technical Specifications
Product Overview
High-Performance Centrifugal Fan
This centrifugal fan is engineered for optimal air movement in HVAC&R, ventilation, and air purification systems. Featuring a compact structure and professional design, it delivers high efficiency with low noise levels for demanding residential and commercial environments. The robust construction, including a dynamically balanced impeller, ensures a long service life and reliable performance across various applications.
Key Features
- Compact and space-saving structure
- Professional aerodynamic design
- Fine process control for durability
- Easy installation and maintenance
- High efficiency with low operational noise
- Long service life for continuous operation
Technical Performance
Performance Metrics
Model Comparison Table
| Model | Voltage (V) | Freq (Hz) | Power (W) | Air Flow (m³/h) |
|---|---|---|---|---|
| YWFB2E225 | 230 | 50/60 | 135 | 1,050 |
| YWFB2E225H | 115 | 60 | 200 | 1,340 |
| YWFB4E225 | 230 | 50/60 | 58 | 620 |
Construction & Materials
- Housing Material
- Galvanized steel
- Impeller Design
- Dynamically balanced galvanized steel impeller
Applications
- Application Areas
- HVAC SystemsAir PurificationRefrigerationMedical TreatmentFresh Air SystemsNew EnergyAuto PartsHousehold Appliances
Compliance & Quality
Certifications
Purchase Information
Order Process
- Style selection and initial communication
- Design document submission and detail confirmation
- Form validation and receivables
- Proofing and bulk production
- Quality inspection and packaging
- Final delivery
Terms and Conditions
Products are shipped according to the agreed schedule after payment. Buyers should inspect the quantity and appearance of goods within 7 days of receipt. Please note that for professional processed items, returns without a valid quality reason are generally not supported; purchasing samples prior to bulk orders is recommended.
