Blow Molding Machine with In-Mold Labeling
This blow molding machine supports double-layer production with a view stripe. It features in-mold labeling, thickness control, and an automatic deflasher.
Technical Specifications
Overview
High-Performance Blow Molding Solution
This advanced blow molding machine is engineered for the efficient production of hollow plastic products under 10L, featuring specialized capabilities for double-layer and view-stripe production. Equipped with a Siemens Intelligent Control System, it offers precise, multi-language operation and energy-saving frequency inverter controls. The robust design includes high-wear-resistant screw barrels, advanced die head technology, and a high-rigidity clamping system to ensure uniform wall thickness and consistent quality.
Technical Capabilities
Production Capacity
10 L
Max Product Volume
Die Head Features
- High-degree isolation design for double-layer and view stripe lines
- Uniform axial thickness
- Deep crystal surface treatment
- Curve runner design with no dead ends
- Easy to refuel and change color
- Optional divergent, spiral, or plastic extrusion die
Extrusion System
- Frequency inverter speed control for energy saving
- Strengthened and hardened screw with cold treatment
- High wear-resistant screw barrel
- Lifting type extruder (adjustable up and down)
Control & Automation
- Control System
- Siemens Automatic Intelligent Control System with multi-language user interface
- Automation Features
- Automatic LubricationInverter Speed Control100-Point Parison ControlAuto Die Head CleaningTelemaintenance
Mechanical Design
Motion System
- Super harden guide column
- Front linear guide rail
- Double proportional valve for oil flow and pressure control
- Clamping System
- Stress-designed template with ductile cast iron station and clamping plate
Safety & Compliance
Safety Features
- Safety door (machine stops when opened)
- Low-temperature startup protection
Optional Equipment
Optional Functions
- Automatic hydraulic filter device
- Down blow pin
- Parison thickness controller
- Scraper and deflasher
