Technical Specifications
Overview
Professional Beverage Solution
This compact automatic vending machine is designed for seamless soft drink dispensing in controlled environments. Featuring a token or coin-operated payment system, it offers a reliable solution for high-traffic commercial spaces. The unit is engineered for convenience, providing three distinct drink options with a user-friendly interface and automated cup delivery.
Technical Specifications
- Power Requirements
- AC220V 50/60Hz 820W
- Dimensions
- 300(W) x 480(D) x 630(H) mm
- Gross Weight
- 19.8 kg
Operational Capacity
Cup Specifications
74 mm
Cup Diameter
80 pcs
Cup Capacity
Water Tank Capacities
- Hot water tank: 2.7L
- Normal temp tank: 1.6L
- Internal water bucket: 4.3L
- Optional external tank: 18.9L
- Drink Supply Types
- 3
- Raw Material Capacity
- 1600g per bucket (3 buckets)
Compliance & Features
Optional Accessories
Building Water ConnectionBottom Water PumpBase Cabinet
- Certifications
- CBCEKCNCCCOCLFGBETLNSF
