Technical Specifications
Overview
High-Performance Air Driven Gas Booster
This air-driven gas booster provides a reliable and efficient solution for generating high-pressure gas without the need for electrical power, making it ideal for explosion-proof environments. It features a robust design with separation between air and gas sections to ensure high purity and zero pollution. With the ability to stall at predetermined pressures and hold without consuming power, it offers an energy-efficient alternative for pressure testing, gas transfer, and accumulator charging.
Key Performance Metrics
Performance Highlights
20,000 psig
Max Outlet Pressure
150 psig
Max Air Drive Pressure
25 :1
Max Compression Ratio
Technical Specifications
Model Performance Comparison
| Model Code | Max Gas Supply (psig) | Max Outlet Inert Gas (psig) | ML Per Cycle | Stall Pressure Formula |
|---|---|---|---|---|
| AGB06-2S-60 | 9000 | 9,000 | 51 | 60 Pa |
| AGB06-2S-100 | 12000 | 12,000 | 32 | 100 Pa |
| AGB06-2S-150 | 20000 | 20,000 | 20 | 150 Pa |
- Gas Port Connections
- 1/4" HF (Female high pressure connection)
Gas Compatibility
- Supported Gases
- AirNitrogen (N2)Helium (He)Carbon Dioxide (CO2)Neon (Ne)Argon (Ar)Oxygen (O2)Hydrogen (H2)Methane (CH4)Natural Gas
Operational Features
Core Features
- No heat, flame, or spark risk during operation
- Infinitely variable cycling speed and output
- No airline lubricator required
- Built-in cooling system
- Double drive, single acting configuration
- Automatic control compatibility
- Zero gas pollution (no lubrication in gas section)
- Explosion Proof
- Yes
Compliance & Safety
Certifications
ATEX ApprovedCE Certified
